Installation [12/2017 - ]: Procedure

  1. INSTALL NO. 2 SATELLITE SWITCH SET (VSC OFF SWITCH)
    1. Install the No. 2 satellite switch set (VSC OFF switch) to the console box ornament with the 3 screws.
      GTY815531Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
  2. INSTALL NO. 1 INSTRUMENT PANEL SAFETY PAD SUB-ASSEMBLY

    Refer to PROCEDURE - Step 28 [12/2017 - 10/2020] , or refer to PROCEDURE - Step 31 [10/2020 - 10/2022] , or refer to PROCEDURE - Step 30 [10/2022 - 10/2023] , or refer to PROCEDURE - Step 30 [10/2023 - ]
