Components [06/2018 - 08/2021]
Fig 1: Transmission Control Cable Replacement Components With Torque Specifications [06/2018 - 08/2021] (1 Of 2)
| *1 | COOL AIR INTAKE DUCT SEAL | *2 | INLET AIR CLEANER ASSEMBLY |
| *3 | NO. 1 ENGINE COVER SUB-ASSEMBLY | *4 | AIR CLEANER ASSEMBLY WITH AIR CLEANER HOSE |
| *5 | FRONT LOWER NO. 1 FLOOR HEAT INSULATOR | *6 | ENGINE ROOM MAIN WIRE |
| N.m (kgf/cm, ft.lbf): Specified torque | - | - |
Fig 2: Transmission Control Cable Replacement Components With Torque Specifications [06/2018 - 08/2021] (2 Of 2)
| *1 | TRANSMISSION CONTROL CABLE ASSEMBLY | *2 | NO. 1 CONSOLE BOX DUCT |
| N.m (kgf/cm, ft.lbf): Specified torque | • | Non-reusable part |
