Circuit Description

This DTC is output when the passenger door power window regulator switch or door control switch is operated.

HINT:

• If this DTC is output when a switch is not operated, one of the switches may be stuck.
• If this DTC is not output when a switch is operated, the switch's contact is defective.
  Fig 1: Power Window Switch Circuit On Passenger Door Circuit Description

  Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
