Driver-Side Kick Panel Fuse Identification: Notes

Fig 1: Driver-Side Kick Panel Fuse Panel Identification
G50F13180Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
Fig 2: Engine Compartment Fuse Panel Identification
G50G13181Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
