Section 1 (Charging System - 3.3L): Alternator: Specifications: Specification
WARNING: This page is about a different variant/trim than selected.
| Item |
Specification |
| Rated voltage |
13.5V, 180A |
| Speed in use |
0 - 18, 000rpm |
| Voltage regulator |
IC Regulator built in type |
| Default regulated voltage (V) |
Regulator (external mode) |
10.6 - 16 |
| Regulator (internal mode) |
14.2 - 14.8 |
| Pin |
1 |
 Courtesy of KIA MOTORS AMERICA, INC.
|
