Signal Waveform & Data

Fig 1: Scantool Display - Normal Waveforms Of OCV-IN & CKPS, CMPS (IN, EX) At Engine Idle
G12282547Courtesy of KIA MOTORS AMERICA, INC.
  1. A: CKPS & CMPS (Intake side) syncronization - There are about 4-5 teeth between the CKPS missing tooth and CMPS signal.
