Monitor GDS Data

  1. Connect GDS to DLC (Data Link Cable).
  2. Select "Air Conditioner System" and perform to inspect regarding ambient temperature sensor with GDS
    Fig 1: Screen Display - Air Conditioner System With GDS
    G11796140Courtesy of KIA MOTORS AMERICA, INC.
    Fig 2: Screen Display - Ambient Temperature Sensor With GDS
    G11796141Courtesy of KIA MOTORS AMERICA, INC.
  3. Are the parameters displayed correctly?

    YES

    • Fault is intermittent caused by poor contact in the sensor's and/or ECM's connector or was repaired and ECM memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and go to "Verification Of Vehicle Repair " procedure.

    NO
