Direct Measurement

WARNING: This page is about a different car, the 2015 Kia Soul EV. However, it is still accessible from the selected car via links, so may be relevant.

Transmission and Reception are executed by one sensor.

(FL, FCL, FCR, FR, RL, RCL, RCR, RR each sensor execution)

Fig 1: RCL And RCR Direction Flow Diagram (Direct Measurement)
G10744641Courtesy of KIA MOTORS AMERICA, INC.
