Home >> Kia >> 2014 >> Forte LX, Automatic Trans >> Repair and Diagnosis >> Transmission >> Automatic Trans >> Hydraulic System - 1.8L >> Oil Cooler >> Components And Components Location >> Components

Components And Components Location: Components

Fig 1: Exploded View Of Oil Cooler With Torque Specifications

G09745750

Courtesy of KIA MOTORS AMERICA, INC.
