Module-Ride Height Switch (Standard) Connector End View (D2788A)

Harness-Family: CONSOLE_CENTER

Color: BLACK

Gender: FEMALE

Part Number: 1456983-3

Part Description: Not Available

Connector No: D2788A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Module-Ride Height Switch Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Module-Ride Height Switch Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

A195

RD/YE

0.50

FUSED B(+)

N/A

D454

0.35

LIN BUS

N/A

Z914

0.50

GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
