Right Side Impact Sensor 1 Connector End View
WARNING: This page is about a different car, the 2009 Dodge Caliber and 2008 Dodge Caliber. However, it is still accessible from the selected car via links, so may be relevant.
SENSOR-SIDE IMPACT-RIGHT 1 - YELLOW 4-WAY
 Courtesy of CHRYSLER CORP.
|
| CAV |
CIRCUIT |
FUNCTION |
| 1 |
R14 20TN/LG |
RIGHT SIDE IMPACT SENSOR 1 SIGNAL |
| 2 |
R16 20BR/LG |
RIGHT SIDE IMPACT SENSOR 1 GROUND |
| 3 |
R20 20WT/LG |
RIGHT SIDE IMPACT SENSOR 2 GROUND |
| 4 |
R18 20LB/LG |
RIGHT SIDE IMPACT SENSOR 2 SIGNAL |
