Module Antenna (Export) Connector End View (C1)

ANTENNA MODULE C1 (EXPORT) - 2 WAY

GCKJ580335Courtesy of DAIMLERCHRYSLER CORP.
CAV CIRCUIT FUNCTION
1 Q39 16RD POWER SUNROOF RELAY OUTPUT
2 - -
