Cooling System Specifications: Specifications: Notes

NOTE: On models with 4.0 L engine, front grill must be removed to access radiator draincock. Draining cooling system can be accomplished by removing drain plug from side of block as well as by loosening radiator draincock. Drain plug is located on lower left side of engine block. See Fig 1.

Fig 1: Locating Engine Block Cooling System Drain Plug (4.0L)

Courtesy of DAIMLERCHRYSLER CORP.
