Home >> Jeep >> 1986 >> Cherokee Base, 2D Utility, 2.1 B, RWD >> Repair and Diagnosis >> Engine Performance >> System >> 2.8L Feedback Carburetor System >> Diagnosis & Testing >> Chart 5

Chart 5

Fig 1: Chart 5, Check Engine Light Inoperative

G9545
