Removal and Installation

CAUTION:

Never bend the pawl of rear door finisher.

REMOVAL

  1. Remove rear door finisher. Refer to REAR DOOR FINISHER : Removal and Installation .
  2. Remove rear power window switch SYMBOL from rear door finisher SYMBOL .
    GNSDB147517Courtesy of NISSAN NORTH AMERICA, INC.
SYMBOL : Pawl

INSTALLATION

Install in the reverse order of removal.
