Work Procedure

• Perform action test to verify the customer's concern.
• Perform action test and check the system operation after system diagnosis.

Warning:

1. CHECK DAA SYSTEM SETTING
   1. 1. Start the engine.
      2. After starting the engine wait for 30 seconds or more.
      3. Check that the DAA system setting can be enabled/disabled on the information display.
      4. Turn OFF the ignition switch and wait for 5 seconds or more.
      5. Check that the previous setting is saved when the engine starts again.

   >>

   GO TO 2.

2. ACTION TEST FOR DAA
   1. 1. Enable the setting of the DAA system on the information display.
      2. Check the DAA operation according to the following table.

         Vehicle condition/ Driver's operation				Display on combination meter
         DAA OFF				-
         DAA ON				Courtesy of NISSAN

   >>

   INSPECTION END
