Component Location

Courtesy of NISSAN NORTH AMERICA, INC.

No.	Component	Function
1.	Rear camera	Refer to Rear Camera .
2.	Around view monitor control unit	Refer to Around View Monitor Control Unit .
3.	Door mirror RH (side camera)	Refer to Side Camera .
4.	ABS (Anti-lock Braking System) actuator & electric unit (control unit)	Provides around view monitor control unit with the wheel speed signal via CAN communication.
5.	Transmission range switch	Provides around view monitor control unit with the reverse signal. Provides AV control unit with the reverse signal.
6.	Front camera	Refer to Front Camera .
7.	TCM (Transmission Control Module)	Provides around view monitor control unit with the transmission range indication signal via CAN communication.
8.	ECM (Engine Control Module)	Provides around view monitor control unit with the engine status signal via CAN communication.
9.	IPDM E/R (Intelligent Power Distribution Module Engine Room)	Provides a pass-through for the reverse signal from the transmission range switch to the AV control unit and around view monitor control unit.
10.	Door mirror LH (side camera)	Refer to Side Camera .
11.	Electric parking brake control module	Provides around view monitor control unit with the parking brake status display signal via CAN communication.
12.	ADAS control unit	Provides around view monitor control unit with the warning driver attention signal via CAN communication.
13.	Sonar control unit	Provides around view monitor control unit with the following via CAN communication: Image display request signal. Status display request signal. Detection level state signal. Detection distance request signal.
14.	Display unit	Refer to Display Unit .
15.	Steering angle sensor	Refer to Steering Angle Sensor .
16.	Combination meter	Provides around view monitor control unit with the following via CAN communication: Hand brake switch signal. Setting change request signal.
17.	BCM (Body Control Module)	Provides around view monitor control unit with the door state signals via CAN communication.
18	Integral switch	Refer to Integral Switch .
19.	Multifunction switch	Refer to Multifunction Switch .
20.	AV control unit	Refer to AV Control Unit . Provides around view monitor control unit with the following via CAN communication: Camera switch press signal. Camera OFF request signal. MOD switch press signal.
