Switch Name and Function

G08857485Courtesy of NISSAN NORTH AMERICA, INC.

No.

Switch name

Description

1

Warning systems switch

Turns LDW system ON/OFF

(When the setting of LDW system in the vehicle information display is ON)

2

LDW system setting screen

(The vehicle information display)

Turns setting of LDW system can be switched between ON and OFF
