DRIVER SIDE : Exploded View

WARNING: This page is about a different car, the 2011 Infiniti EX35. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Identifying Foot Lamp Components (Driver Side)
G07163028Courtesy of NISSAN MOTOR CO., U.S.A.
