Section 1 (Front Suspension System (2WD))
>>
Removal And Installation
>>
Transverse Link
>>
Exploded View
Exploded View
WARNING:
This page is about a different variant/trim than selected.
Fig 1: Exploded View Of Transverse Link With Torque Specifications
Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
Refer to "
COMPONENTS
" for symbols in the figure.
