Removal and Installation: Removal

WARNING: This page is about a different car, the 2006 Nissan Xterra. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove rear combination lamp bolts (1).
    • Rear combination lamp locator (3)
  2. Pull the lamp assembly (2) rearward to remove from the vehicle.
  3. Disconnect the connector and remove the rear combination lamp.
Fig 1: Disconnecting Connector
G04206216Courtesy of NISSAN MOTOR CO., U.S.A.
