Nighttime Mode

Unified meter control unit is transferred to nighttime mode, with ignition switch turned ON and position light request signal from BCM with CAN communication.
When nighttime mode, illumination control switch illumination turns ON by unified meter control unit. Each illumination is controlled by unified meter control unit.
Each illumination can be adjusted to 16 step by illumination control switch in nighttime mode.

NOTE: For further details of illumination circuit, refer to "ILLUMINATION ".

Fig 1: Identifying Contrast Control Switch

Courtesy of NISSAN MOTOR CO., U.S.A.
