Intake Air Temperature Sensor

  1. Check resistance between mass air flow sensor terminals 5 and 6 under the following conditions.
    Fig 1: Checking Resistance Between Mass Air Flow Sensor Terminals 5 And 6
    G00731085Courtesy of NISSAN MOTOR CO., U.S.A.
  2. If NG, replace mass air flow sensor (with intake air temperature sensor).
