Ground Circuit Inspection

  1. Ignition "OFF".
  2. Disconnect IATS connector.
  3. Measure the resistance between ground terminal of IATS harness connector and chassis ground.

    Specification:  Approx. 0Ω

    Fig 1: Measuring Resistance Between Ground Terminal Of IATS Connector And Chassis Ground
    G07272219Courtesy of HYUNDAI MOTOR CO.
  4. Is resistance within the specification?

    YES

    • Go to next step as below.

    NO
