Signal Circuit Inspection

  1. IG "OFF" and disconnect P/S pressure sensor connector and ECM connector.
  2. Measure the resistance between signal terminal of P/S pressure sensor harness connector and chassis ground.

    Specification:  Approx. 0V

    Fig 1: Measuring Resistance Between Signal Terminal Of P/S Pressure Sensor Harness Connector And Chassis Ground
    G07252092Courtesy of HYUNDAI MOTOR CO.
  3. Is the measured resistance within specification?

    YES

    NO
