Inspection Outline
- The components to be tested are indicated by a dotted line.
- The illustration does not show all of the areas to be inspected.
| Inspection Items | Work Items | |
|---|---|---|
| a | Body Control Module | Keyless Access System Inspection 1 |
| Keyless Access System Inspection 2 | ||
| b | Gauge Control Module | Gauge Control Module Inspection |
| c | Fuel and Emissions Systems | Fuel and Emissions Systems Inspection |
