Keyless Access Control Unit - Diagnostics
>>
Troubleshooting
>>
DTC B1663
>>
Inspection Outline
Inspection Outline
The illustration does not show all of the areas to be inspected.
Courtesy of HONDA, U.S.A., INC.
Inspection Items
Work Items
a
External Circuit
EXT_R+, EXT_R- Shorted Wire Inspection
b
Body Control Module
Body Control Module Inspection
c
Rear Interior LF Antenna
Rear Interior LF Antenna Inspection
Courtesy of HONDA, U.S.A., INC.
