Camshaft Position (CMP) Sensor A

CMP sensor A detects camshaft angle position for the VTC system.

Fig 1: Identifying Camshaft Position (CMP) Sensor A

G03673928

Courtesy of AMERICAN HONDA MOTOR CO., INC.
