Diagnostic Aids

A misadjusted TPS could cause Code 45 to set. Before replacing TPS, check TPS adjustment. Refer to ADJUSTMENTS article in this section.

Fig 1: Code 45 Schematic, Idle Switch Circuit Circuit Grounded Or Misadjusted TPS
G92B26923
Fig 2: Code 45 Flow Chart, Idle Switch Circuit Circuit Grounded Or Misadjusted TPS
G92C26940
