Diagnostic Aids
Improper fuel system pressure can result in one of the following symptoms:
- Cranks, but will not run.
- Cuts out, may feel like ignition problem.
- Poor fuel economy, loss of power.
- Hesitation.
NOTE:
For circuit schematic, see Figure
.
