Charging System: Alternator
WARNING: This page is about a different variant/trim than selected.
| Item |
Specification |
| Rated voltage |
13.5V, 180A |
| Speed in use |
0 - 18000 rpm |
| Voltage regulator |
IC Regulator built in type |
| Default regulated voltage (V) [COM terminal] |
Regulator (External mode) |
10.6 - 16 |
| Regulator (Internal mode) |
14.2 - 14.8 |
| Pin |
1 |
 Courtesy of HYUNDAI MOTOR AMERICA
|
