Repair Procedures: Removal

  1. Disconnect the negative (-) battery terminal.
  2. Remove the tailgate back panel.

    (Refer to Body - "LIFTGATE BACK PANEL ")

  3. Loosen the mounting screws and remove the rear camera (A).
G14727808Courtesy of HYUNDAI MOTOR AMERICA
