Knock Sensor Replacement (Position 1)

Fig 1: Knock Sensor (Position 1)

Courtesy of GENERAL MOTORS COMPANY

Callout	Component Name
Preliminary Procedure  Starter Replacement (LTG - All Wheel Drive)Starter Replacement (LTG - Front Wheel Drive)
1	Electrical Connector
2	Knock Sensor Fastener CAUTION: Refer to Fastener Caution . Tighten  25 N.m (18 lb ft)
3	Knock Sensor
