Installation Procedure

    Fig 1: Tank Cover
    GM2917235Courtesy of GENERAL MOTORS COMPANY
  1. Lift tank cover (1) over the tank.
    2. Fig 2: Tank Cover Bolts
    GM2917237Courtesy of GENERAL MOTORS COMPANY
  2. Install the four lower bolts (1) to the tank cover (2) and torque to 22 (16 lb ft).
    3. Fig 3: Tank Cover
    GM2917232Courtesy of GENERAL MOTORS COMPANY
  3. Install the five bolts (1) to the top of the tank cover (2) and torque to 22 (16 lb ft).
