Installation Procedure

  1. Connect the electrical connector.
    2. Fig 1: View Of Temperature Sensor
    GM299160Courtesy of GENERAL MOTORS CORP.
  2. Install the temperature sensor by sliding the temperature sensor downward.
  3. Install the radiator grille. Refer to Grille Replacement (GMC) or Grille Replacement (Chevrolet) in Exterior Trim.
