Hydraulic Control Unit (HCU): Removal

NOTE: If the fluid is spilled on the paintwork, the affected area must be immediately washed down with cold water.

NOTE: The HCU and ABS module are serviced as an assembly.

NOTE: Removal steps in this procedure may contain installation details.

1.

If installing a new HCU/ ABS module, upload the Anti-Lock Brake System (ABS) module configuration to the scan tool. REFER to: Module Configuration - System Operation and Component Description
