| 1 |
15S-TA65 (GN-WH) |
20 |
CTRL MOD. - POWERTRAIN # SOLENOID SHIFT CONTROL SSE |
|
| 2 |
91S-TA17 (BK-RD) |
20 |
CTRL MOD. - POWERTRAIN # TRANSMISSION SOLENOID POWER CONTROL (TSPC) |
|
| 3 |
15S-TA63 (GN-BK) |
20 |
CTRL MOD. - POWERTRAIN # SOLENOID SHIFT CONTROL SSC |
|
| 4 |
9-TA36 (BN-GN) |
20 |
CTRL MOD. - TRANSMISSION FLUID TEMPERATURE (TFT) SIGNAL RETURN |
|
| 5 |
15S-TA17 (GN-OG) |
20 |
SENSOR - TRANSMISSION FLUID TEMPERATURE (TFT) |
|
| 6 |
15S-TA23 (GN-YE) |
20 |
CTRL MOD. - POWERTRAIN # SOLENOID SHIFT CONTROL SSA |
|
| 7 |
8-TA36 (WH-GN) |
20 |
CTRL MOD. - POWERTRAIN # SOLENOID PRESSURE CONTROL PCA |
|
| 8 |
15S-TA24 (GN-BU) |
20 |
CTRL MOD. - POWERTRAIN # SOLENOID SHIFT CONTROL SSB |
|
| 9 |
15S-TA64 (GN-OG) |
20 |
CTRL MOD. - POWERTRAIN # SOLENOID SHIFT CONTROL SSD |
|
