Interior/Map Lamps Assembly, Front Connector End View (C931C)

Fig 1: Identifying Interior/Map Lamps Assembly, Front Connector (C931C)
G09083986Courtesy of FORD MOTOR CO.
Pin Circuit Gauge Circuit Function Qualifier
1 31S-LB25 (BK-BU) 20 LUGGAGE~COMPARTMENT ~LAMP, SWITCHED GROUND POWER RETURN
1 31S-LB25 (BK-BU) 20 LUGGAGE~COMPARTMENT ~LAMP, SWITCHED GROUND POWER RETURN
