Heated Seat Switch: Notes

Fig 1: Identifying Heated Seat Switch Components
G07981269Courtesy of FORD MOTOR CO.
Item Part Number Description
1 5404644 Lower finish panel
2 - Connector (part of 14401)
3 14D694 Heated seat switch
