Mass Air Flow (MAF) Sensor: Notes
WARNING: This page is about a different car, the 2009 Ford RV Cutaway, 2009 Ford Econoline, 2009 Ford E450 Super Duty, and 2009 Ford Cutaway. However, it is still accessible from the selected car via links, so may be relevant.
ITEM DESCRIPTION
| Item | Part Number | Description |
|---|---|---|
| 1 | 9A612 | Air Cleaner (ACL) tray |
| 2 | 9628 | ACL clamp |
| 3 | 9A628 | Mass Air Flow (MAF) sensor body |
| 4 | 9643 | ACL cover |
| 5 | - | Engine harness-to- MAF sensor pigtail electrical connector (part of 12A581) |
| 6 | 12A690 | MAF sensor pigtail electrical connector |
| 7 | W709287 | MAF sensor screw (2 required) |
| 8 | 12B579 | MAF sensor |
