Item 97: Manual Control Lever Shaft Seal Disassembly Note
- Remove the manual control lever seal.
- After cleaning the main control valve body, carry out the following.
- Inspect all valve and plug bores for scoring or burrs.
- Check all fluid passages for obstructions.
- Inspect all valves and plugs for burrs.
- Inspect all mating surfaces for burrs or distortion.
- Inspect all springs for distortion.
- Check all valves and plugs for free movement in their respective bores.
- Valves and plugs, when dry, must fall from their own weight into their respective bores.
- Roll the manual valve on a flat surface to check for a bent condition.
- Assemble in the reverse order of disassembly.
CAUTION:
Do not damage the bore.
