Pinpoint Test C: The Engine Does Not Reach Normal Operating Temperature

WARNING: This page is about a different car, the 2002 Ford Escort. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Pinpoint Test C: Engine Does Not Reach Normal Operating Temperature
G03444918Courtesy of FORD MOTOR CO.
