Smart Junction Box (SJB) C2280b

WARNING: This page is about a different car, the 2005 Ford Mustang. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Identifying Smart Junction Box (SJB) C2280b
G03986230Courtesy of FORD MOTOR CO.
