Driver Power Mirror Motor Connector End View
POWER MIRROR MOTOR-DRIVER
 Courtesy of DAIMLERCHRYSLER CORP.
|
| CAV |
CIRCUIT |
FUNCTION |
| 1 |
18BK/RD |
FUSED OPTIONAL EQUIPMENT RELAY OUTPUT |
| 2 |
18BR |
GROUND |
| 3 |
18WT/DG |
DRIVER MIRROR HORIZONTAL MOTOR DRIVER |
| 4 |
18DG/RD |
DRIVER MIRROR VERTICAL MOTOR DRIVER |
| 5 |
18BL/BR |
DRIVER MIRROR COMMON DRIVER |
