Boost Pressure Sensor (OBD) Connector End View
Boost Pressure Sensor (OBD) Connector End View
BOOST PRESSURE SENSOR (OBD)
Courtesy of DAIMLERCHRYSLER CORP.
CAV
CIRCUIT
FUNCTION
1
18BR/WT
SENSOR GROUND
2
18WT/DG
BOOST PRESSURE SENSOR SIGNAL
3
18WT/RD
BOOST PRESSURE SENSOR 5 VOLT SUPPLY
Courtesy of DAIMLERCHRYSLER CORP.
