Air Outlet Temperature Sensor Connector End View

AIR OUTLET TEMPERATURE SENSOR

Courtesy of DAIMLERCHRYSLER CORP.
CAV	CIRCUIT	FUNCTION
1	18BR/GY	AIR OUTLET TEMPERATURE SENSOR SIGNAL
2	18BR/BL	SENSOR GROUND
