Body Plug Connector Connector End View

BODY PLUG CONNECTOR

GCVA580024Courtesy of DAIMLERCHRYSLER CORP.
CAV CIRCUIT FUNCTION
1 14BL/YL D(+) RELAY NO. 2 OUTPUT
2 14RD FUSED B(+)
3 14BK/YL FUSED IGNITION SWITCH RUN-START RELAY OUTPUT
