Blower Motor Resistor Block Connector End View
BLOWER MOTOR RESISTOR BLOCK
 Courtesy of DAIMLERCHRYSLER CORP.
|
| CAV |
CIRCUIT |
FUNCTION |
| 1 |
12YL/BK |
BLOWER MOTOR M2 DRIVER |
| 2 |
12YL |
BLOWER MOTOR LOW DRIVER |
| 3 |
12WT/BK |
BLOWER MOTOR M1 DRIVER |
| 4 |
12DG |
BLOWER MOTOR HIGH DRIVER |
