Module-Memory Mirror: Removal

  1. Disconnect and isolate the battery negative cable.
  2. Remove the door trim panel (Refer to PANEL-TRIM ).
  3. Disconnect the electrical connector (3) from module (1).
  4. Remove fasteners (2) and module (1) from vehicle.
    Fig 1: Removing Memory Mirror Modules
    G03519798Courtesy of DAIMLERCHRYSLER CORP.
