Driver Door Lock Switch: Installation

WARNING: This page is about a different car, the 2006 Chrysler Crossfire. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Identifying Door Lock Switch Locking Tab & Pneumatic Supply Line

Courtesy of DAIMLERCHRYSLER CORP.

NOTE: Ensure the harness is routed and secured in its original position to avoid potential interference with moving parts.

Install the door harness assembly into the door.
Install the driver door lock switch into the door latch assembly (1).
Install the door watershield.
Install the door interior trim panel. (Refer to BODY/DOOR - FRONT/TRIM PANEL - INSTALLATION) .
Connect the negative battery cable.
